Ultrasound In The Food Industry

The application of power ultrasound is used for numerous application in food processing, including extraction, homogenization, pasteurization and fermentation. As a non-thermal treatment, ultrasonication improves food production processes by higher yields, higher quality, improved nutrient and flavour profiles as well as time- and cost-saving processing.

Ultrasonic Applications in Food Processing

Power ultrasound has a wide range of applications in food processing, including extraction, mixing, emulsification, pasteurization, degasssing and meat tenderization. Besides these main applications, power ultrasound is also applied to improve freezing, thawing and drying of food products.
The major advantages of high-intensity ultrasonics are related to the improvement of various food processing operations, such as reducing processing time, increasing yields, improving product quality and allow for more cost- and time-saving, economical processing.

In the following paragraph, you can find the main applications of high-intensity ultrasonics in the food industry:

  • Extraction: Ultrasound can be used to extract bioactive compounds from plant materials, such as antioxidants, pigments, and essential oils. This process is known as sonication-assisted extraction and can be used to produce high-quality extracts in a shorter time and with lower solvent consumption than traditional methods.
  • Homogenization and Emulsification: Ultrasonic homogenization can be used to produce stable emulsions and suspensions, such as salad dressings, mayonnaise, creams, and dairy products. The process involves using high-frequency sound waves to break down the fat globules in the liquid, resulting in a smooth and uniform texture.
  • Preservation: High-intensity ultrasound can be used to inactivate microorganisms, such as bacteria and yeasts, in food products. The process, known as sonication-assisted pasteurization, can extend the shelf life of food products and reduce the risk of foodborne illnesses. As a non-thermal processing technique, sonication prevents the use of very high temperatures and the related degradation of heat-sensitive nutrients.



Do you want to produce your own spice extracts or sauces? Whether for the restaurant kitchen, the ambitious sous chef or for commercial manufacturers, with Hielscher ultrasonic equipment you can produce high-quality extracts and sauces in a short time. Make organic extracts yourself! Eliminate preservatives! Use only the ingredients you select!

Chili Pepper Extraction - Hielscher ultrasonicator UP200HT

Video Thumbnail



Information Request




Note our privacy policy.


Ultrasonic inline homogenizer for juice, dairy and liquid egg pasteurization

Ultrasonic homogenizers are widely used in food processing. Typical applications include extraction, mixing, emulsification and ageing / maturation.

  • Degassing: With the application of ultrasound to a liquid, gas bubbles entrapped in liquids are agitated. As a consequence, these air and gas bubbles come close to each other and coalesce. Theis means they grow to a larger bubble size which enables them to float to the top of the liquid and can be easily removed.
  • Dissolving: Due to its outstanding mixing and blending capabilities, ultrasound is highly effective to produce highly saturated and even supersaturated solutions. This is used in crystallization processes as well as in the production of brines.
  • Fermentation: As ultrasound waves perforate and break down the cell walls of the microorganisms, they get more susceptible to the fermentation process. At the same time, ultrasound accelerates the transport of nutrients and oxygen to the microorganisms, thereby enhancing their metabolic activity. Overall, ultrasonication increases the rate of fermentation, reduce fermentation time, and improve the yield of the desired end-product. This technology is particularly useful for the production of food and beverage products, such as dairy, yogurt, beer, kombucha, and wine.
  • Viscosity Reduction before Spray Drying: Ultrasonic shear forces can reduce the viscosity in shear-thinning and thixotropic slurries significantly. Applying ultrasonic shear-thinning before spraying and spray dryers allows to increase the through-put through the spraying equipment significantly. Spray-drying towers are often the bottle-neck in production line. With ultrasound, the capacity of existing spray-dryers can be increased.



Hielscher ultrasonicators can homogenizes and pasteurize liquid egg products (whole eggs, egg whites, yolks) to ensure food safety and mechanical stability. Hielscher ultrasonic homogenizers deliver intense cavitation and high shear forces to kill microbes. Ultrasonic pasteurization is a very effective and efficient low-temperature pasteurization alternative. Liquid egg pasteurized by ultrasonication shows less protein denaturation, lower flavour loss, improved homogeneity and significantly higher energy-efficiency.

Liquid Egg Homogenization and Pasteurization Applying Power Ultrasound with the Ultrasonicator UP400ST

Video Thumbnail



Ultrasonic batch reactor for industrial food processing such as homogenization, extraction, or pasteurization .

The closed batch reactor made from stainless steel is equipped with the ultrasonicator UIP2000hdT (2kW, 20kHz).

  • Freezing: Ultrasonic freezing can be used to reduce the formation of ice crystals in food products during the freezing process. The process involves subjecting the food to high-frequency sound waves while it is being frozen. Ultrasound waves create vibrations that prevent the formation of large ice crystals, resulting in a product with a smoother texture and better quality.
  • Thawing: Ultrasonic thawing can be used to reduce the thawing time of frozen food products. The process involves subjecting the frozen product to ultrasound waves, which generate heat and accelerate the thawing process. Since ultrasound promotes a very uniform distribution of energy, ultrasonic thawing can be particularly useful for products that are difficult to thaw evenly, such as meat, seafood, fruits and vegetables.
    In freezing, thawing and drying, power ultrasound causes significant improvements in mass and energy transfer processes, which accelerates these processes and make them more economical.
  • Bottle Leak Detection: Ultrasound is a very efficient way to detect leaks and cracks in bottles and cans of carbonic beverages such as soda, beer, sparkling wine etc. Ultrasonics is also applied in the degassing of carbonated beverages, e.g., beer before bottling, a process known as de-fobbing.
  • Brining / Pickling: Brining is common process in the preservation and manufacturing of foods, especially for meat, fish, cheese and vegetables. Ultrasonication shortens the brining time and allows to use reduced amounts of sodium chloride in comparison to traditionally brined foods and pickles.
  • Hydration / Rehydration: Power ultrasound is a simple, yet highly effective method to hydrate or re-hydrate food products such as dried pulses (e.g. beans, chickpeas) or dehydrated mushrooms. Since ultrasound opens cellular pores in food, water can penetrate quickly. This leads to accelerated swelling of pulses and subsequently a shorter cooking time.
  • Decrystallization of Honey: As a non-thermal treatment, ultrasound is effectively used to prevent the formation of large sugar crystals in honey. Furthermore, already formed large crystals in honey can be decrystallized by ultrasound treatment. As highly effective dissolving technique, probe-type ultrasonicators dissolve sugar crystals resulting in a uniformly smooth honey. Additionally, ultrasound improves the microbiological quality of honey since unwanted microbes are inactivated due to the effect of ultrasonic cell disruption.
  • Frying: Ultrasonic frying can be used to reduce oil absorption in fried food products. The process involves immersing the meat or vegetable in hot oil while subjecting it to high-frequency sound waves. The ultrasound waves create small bubbles on the surface of the food, which reduce the contact area between the vegetable / meat and the oil, resulting in less oil absorption and a healthier final product. Ultrasonic frying allows to cook food at lower temperatures creating superior flavour profiles, preserving nutrients.
Degassing and defoaming of liquids is an interesting application of ultrasonic devices. In this case the ultrasound removes dissolved CO2 from beer. Using Hielscher ultrasonic equipment you can degas or defoam liquids in beakers, tanks or inline (flow cell reactors).

Rapid Foaming Using Ultrasonics

Video Thumbnail



Information Request




Note our privacy policy.


High-Performance Ultrasonicators for Food Processing

UIP4000hdT flow cell for inline sonication on industrial scaleHielscher Ultrasonics industrial ultrasonic processors are high-performance ultrasonicators, which are precisely controllable and allow thereby for reproducible outcomes and continuous product quality. Being capable to deliver very high amplitudes, Hielscher ultrasonic processors can be used for very demanding applications.
Customers are satisfied by the outstanding robustness and reliability of Hielscher Ultrasonics systems. Hielscher ultrasonicators reliably run in fields of heavy-duty application, demanding environments and 24/7 operation and ensure thereby efficient and economical food processing. Ultrasonic process intensification reduces processing time and achieves better results, i.e. higher quality, higher yields, novel products.
By means of consistent application of special materials, as e.g. titanium, stainless steel, ceramic or glass of different grades, the compatibility of the technique with the process is guaranteed.
Ultrasonic processors are operator-friendly and convenient machines with low maintenance and a relatively low cost.

The table below gives you an indication of the approximate processing capacity of our ultrasonicators:

Batch Volume Flow Rate Recommended Devices
0.5 to 1.5mL n.a. VialTweeter
1 to 500mL 10 to 200mL/min UP100H
10 to 2000mL 20 to 400mL/min UP200Ht, UP400St
0.1 to 20L 0.2 to 4L/min UIP2000hdT
10 to 100L 2 to 10L/min UIP4000hdT
15 to 150L 3 to 15L/min UIP6000hdT
n.a. 10 to 100L/min UIP16000
n.a. larger cluster of UIP16000

Contact Us! / Ask Us!

Ask for more information

Please use the form below to request additional information about ultrasonic food processors, specific applications, technical details and prices. We will be glad to discuss your process with you and to offer you an ultrasonic system meeting that improves your food processing!









Please note our privacy policy.


Design, Manufacturing and Consulting – Quality Made in Germany

Hielscher ultrasonicators are well-known for their highest quality and design standards. Robustness and easy operation allow the smooth integration of our ultrasonicators into industrial facilities. Rough conditions and demanding environments are easily handled by Hielscher ultrasonicators.

Hielscher Ultrasonics is an ISO certified company and put special emphasis on high-performance ultrasonicators featuring state-of-the-art technology and user-friendliness. Of course, Hielscher ultrasonicators are CE compliant and meet the requirements of UL, CSA and RoHs.



Facts Worth Knowing

How Does Ultrasonics in Food Processing Work?

Ultrasonic food processing is a well established technology used for food processing applications such as mixing and homogenization, emulsification, extraction, dissolving, degassing & deaeration, meat tenderisation, crystallization as well as functionalization and modification of intermediates and final food products. Being installed a since decades in food production plants, Hielscher ultrasonic food processors are sophisticated and developed to meet the industry requirements. Ultrasonic processors apply physical forces created by power ultrasound waves, which results in the generation of cavitation.

What is Acoustic Cavitation?

Acoustic cavitation, also known as ultrasonic cavitation, is the growth and collapse of minute vacuum bubbles in an ultrasonic field generated in liquids or slurries. The cavitation bubbles grow during the alternating high-pressure / low-pressure cycles, which are compression and rarefaction phases respectively. After having been grown over several alternating pressure cycles, the vacuum bubble reaches a point where it cannot absorb more energy so that the bubble implodes violently during a high-pressure cycle. During the bubble collapse, locally extreme conditions occur including extreme temperatures of up to 5,000K with very high heating and cooling rates, pressures of up to 2000atm and corresponding pressure differentials, and liquid jets with up to 280m/s velocity. In these cavitational “hot-spots”, locally extreme forces create physical conditions, which result in mixing, extraction and increased mass transfer.

Acoustic or ultrasonic cavitation: bubble growth and implosion

Acoustic cavitation, generated by high-intensity, low-frequency ultrasound, creates intense shear forces and locally occurring high pressure and temperature differentials, which provide the necessary impact for intense mixing and mass transfer. These ultrasonic shear forces are successfully applied for food processing.

Literature/References

The ultrasonic homogenizer UIP6000hdT is an industrial-grade food processor for mixing, blending and extracting applications with high throughput.

Ultrasonic homogenizer UIP6000hdT installed in a food processing plant.




UP400St agitated 8L extraction setup

Ultrasonic extraction of botanicals with the ultrasonicator UP400St
